Tripp Lite by Eaton PDU3V6H50A 45-Outlets PDU

Tripp Lite by Eaton PDU3V6H50A 45-Outlets PDU

3-Phase 208V PDU Distributes Network-Grade Power to Multiple Loads
This basic PDU is an ideal no-frills unit for networking, telecom, security, audio/video and sound reinforcement applications. Recommended for small to mid-sized data centers, computer rooms and network closets, the PDU3V6H50A features 36 C13, six C19 and three NEMA L6-30R outlets in three breakered single-phase output load banks for connecting equipment. A six-foot (1.8-meter) cord with Hubbell 50A CS8365C (3P+E) 3-phase input plug connects to your facility's AC power source, generator or protected UPS system to distribute power to connected loads.

Easy to Install Vertically in an EIA-Standard 19 in. Rack
The 70-inch 0U PDU's all-metal housing mounts vertically using the pre-installed toolless mounting buttons or the included brackets. Spare buttons are also included. Use the included PDUMVROTATEBRKT kit to install the PDU with outlets facing the rear for better airflow or equipment access. Cable retention brackets keep power cords organized and your rack free of clutter. The PDU's switchless design helps prevent an accidental shutdown, which could lead to costly downtime.

TAA-Compliant for GSA Schedule Purchases
The PDU3V6H50A is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.

• PDU provides power control as remote controlled relay & load monitoring


• Basic PDU deliver power to wiring closets, server rooms & equipment racks in a cost-effective way

Product Type: PDU
Environmentally Friendly: Yes
Taa Compliant: Yes
Mounting Orientation: Vertical/Toolless
Country Of Origin: Taiwan
Rack Height: 0U
Brand Name: Tripp Lite by Eaton
Manufacturer: Tripp Lite by Eaton
Product Model: PDU3V6H50A
Product Name: PDU3V6H50A 45-Outlets PDU
Mount Type: Rack-mountable
Manufacturer Part Number: PDU3V6H50A
Manufacturer Website Address: https://tripplite.eaton.com/
Package Contents:

• PDU3V6H50A 45-Outlets PDU
• Plug Retention Brackets With Installation Hardware
• Rack-mounting Hardware
• Owner's Manual

Limited Warranty: 2 Year
Weight (Approximate): 6.58 kg
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
